CONSTELLATION

    DELPHINUS MK2

    2 way Bookshelf

    Delphinus is the ideal solution for those looking for a loudspeaker with outstanding performance. At twice the sensitivity level of the Lynx, the Delphinus requires half the input power to produce the same sound pressure. Dynamics extends down to 57 Hz, and the natural timbre and amplitude characteristics of the soundstage can reach levels that are inappropriate for its size. Delphinus custom stands further dampen cabinet structure vibrations by calibrating the distance between the stand and loudspeaker to maximize the effectiveness of the low frequency reflection system.






    Concept & Idea


    The Delphinus idea is to present a captured concept that we apply to all of our loudspeakers. Any explanation can only be part of the listening experience that these speakers can provide.



    • Technical Data

      Low Frequency Load

      Vented NRS


      Configuration

      2 way Bookshelf


      Drivers

      1 Tweeter 38 mm Soft Dome Wave Guide

      1 Woofer 170 mm Paper Compound


      Sensitivity

      90 dB SPL / normalized to 1m / 2. 83 Vrms

      decorrelated L/R

      Pink Noise ITU-R BS 1116-1 compliant listening room


      Low Frequency Cut Off

      55 Hz @ -3 dB referred to C4 WETS


      Crossover Frequency

      1500 Hz - LKR 4th order


      Rated Impedance

      Modulus 4 Ω (min 3.0) Argument ± 36°

    • Cabinet & Dimension

      Cabinet

      Solid walnut and HDF.


      Size & Weight

      410 x 230 x 330 mm (H x W x D) / 12 Kg

    • Acoustic Environment & Amplification

      Speakers Orientation

      Speakers should be tilted inward facing the listener


      Listening Layout

      A carpeted floor in front of the speakers is recommended


      Side and Back Walls

      Should be at least 1m away from the speaker front baffle


      Suggested Amplifier

      120 W/4 Ω Max Average Power

    Oriented to Your House

    Constellation Delphinus Mk2

    This loudspeaker is designed to provide excellent performance even in typical home environments where acoustic considerations are largely ignored. The size of the ideal listening environment should be at least 9 square meters and no more than 20 square meters. The minimum power amplification suggested to fully exploit the characteristics of the speaker is 30W/4Ω.
